Industrial 480V 3PH 50A Trigger
Industrial Trigger
Hardwired high-voltage control for 480V 3-phase industrial tools.
The Industrial 480V 3PH Trigger brings GRIT automation to high-voltage CNC routers, dust collectors, and plant equipment — a 50A 3-phase contactor pre-wired into a steel enclosure sized for 480V field wiring, with the same dust collection, runtime logging, and access-control features as every other Trigger in the line.
Key Features
- 50A 3-phase contactor: Rated for 480V continuous duty, higher amperage available on request
- Metal field enclosure: 12" x 12" x 4" steel housing with 24 knockouts
- Automated dust collection: Opens blast gates and starts collectors on tool-on
- Access control lockout: Blocks power until an authorized badge is scanned
- Status LEDs: Red & Green indicators show locked, idle, or running
Specifications
- SKU GA-TR3003
- Voltage 480V
- Amperage 50A continuous
- Phase 3-phase (3PH)
- Enclosure 12" x 12" x 4" steel
- Knockouts 24, 1/2" to 1-1/4"
- Connectivity GRIT Mesh Network
- Status Red/green LEDs
In the Box
- 1x GRIT Industrial 480V 3PH 50A Trigger (GA-TR3003)
- Pre-wired 50A 3-phase contactor in 12" x 12" x 4" metal enclosure
Compatibility
For 480V 3-phase tools drawing up to 50A. Higher-amperage contactors available on request. Pro GRIT Track is required for RFID-enabled systems — contact GRIT for details.
Installation
Mount the enclosure near the tool disconnect and land line and load conductors on the contactor terminals. We recommend a licensed electrician for all hardwired installations.
*GRIT Hub is required for device functionality.
Important Notes
Professional electrical installation recommended. Systems with GRIT Track require a software upgrade (+20%) — contact us before ordering so we can configure your devices.
